Advanced Aluminum Foil-Faced Glass Wool Blanket – Superior Thermal & Acoustic Barrier

Advanced Aluminum Foil-Faced Glass Wool Blanket – Superior Thermal & Acoustic Barrier
Advanced Aluminum Foil-Faced Glass Wool Blanket – Superior Thermal & Acoustic Barrier Advanced Aluminum Foil-Faced Glass Wool Blanket – Superior Thermal & Acoustic Barrier Advanced Aluminum Foil-Faced Glass Wool Blanket – Superior Thermal & Acoustic Barrier Advanced Aluminum Foil-Faced Glass Wool Blanket – Superior Thermal & Acoustic Barrier Advanced Aluminum Foil-Faced Glass Wool Blanket – Superior Thermal & Acoustic Barrier
Informacion basica
Lugar de origen: Porcelana
Nombre de la marca: FANRYN
Cantidad de orden mínima: 1 40HC
Detalles de empaquetado: Bolsa de plástico
Tiempo de entrega: 15 días laborables
Condiciones de pago: T/T
Mejor precio Contactar ahora
Información detallada
Densidad: 40 - 200 kg/m³ Aplicaciones: Aislamiento de edificios, aislamiento industrial, sistemas HVAC.
Conductividad térmica: 0,035 - 0,045 W/m·K Absorción de agua: bajo
Espesor: 20 mm a 100 mm Método de instalación: Fijación mecánica o adhesivo
Fuerza compresiva: ≥ 10kPa Material: Lana mineral
Coeficiente de absorción de sonido: 0,7 - 1,0 color: Normalmente marrón o amarillento
Resistencia al fuego: No combustible, Clase A1 Impacto ambiental: Reciclable y respetuoso con el medio ambiente
Resistencia a la temperatura: Hasta 1000 ° C Dimensiones: Personalizable (p. ej., tableros de 600x1200 mm)
Resaltar:

aluminum foil glass wool blanket

,

thermal insulation mineral wool blanket

,

acoustic barrier glass wool blanket

Descripción de producto

Advanced Aluminum Foil-Faced Glass Wool Blanket – Superior Thermal & Acoustic Barrier
Product Overview:

Our Aluminum Foil-Faced Glass Wool Blanket combines high-performance centrifugal glass wool with a durable Foil-Scrim-Kraft (FSK) facing. This triple-layer facing includes aluminum foil for radiant heat reflection, a reinforcing scrim for strength, and a kraft paper backing for added stability. The result is an insulation product that excels in thermal efficiency, moisture resistance, and acoustic control.

Advanced Aluminum Foil-Faced Glass Wool Blanket – Superior Thermal & Acoustic Barrier 0 Advanced Aluminum Foil-Faced Glass Wool Blanket – Superior Thermal & Acoustic Barrier 1
Product parameter of the glass wool blanket
Item Unit Index Standard
Bulk density kg/m3 10-48 GB/T 5480.3-1985
Average fiber dia. µm 5.5 GB/T 5480.4-1985
Water content % ≤1 GB/T 3007-1982
Grade of combustibility Non-combustible Grade A GB 8624-1997
Preshrinking temp ℃ ≥250 GB/T 11835-1998
Thermal conductibility w/m.k 0.031-0.043 GB/T 10294-1988
Hydrophobicity % ≥98.2 GB/T 10299-1988
Moisture rate % ≤5 GB/T 16401-1986
Sound absorption coefficient 1.03 product reverberation method 24kg/m32000HZ GBJ 47-83
Slag inclusion content % ≤0.3
Density(kg/m3) Thickness(m) Thermal conductibility(W/m.k) Thermal resisitance(m2.K/W)
10 0.05 0.043 1.163
10 0.1 0.043 2.326
12 0.05 0.042 1.190
12 0.1 0.042 2.381
14 0.05 0.041 1.220
14 0.1 0.041 2.439
16 0.05 0.039 1.282
16 0.1 0.039 2.564
20 0.025 0.038 0.658
20 0.05 0.038 1.316
24 0.025 0.036 0.694
24 0.05 0.036 1.389
32 0.025 0.034 0.735
32 0.05 0.034 1.471
48 0.025 0.033 0.758
48 0.05 0.033 1.515
Product size of the glass wool blanket
Density(kg/m3) Thickness(m) Length (m) Width (m) Rolls/packing
10-48 0.025-0.2 5-30 0.6 2 rolls
10-48 0.025-0.2 5-30 1.1 1 roll 2 rolls overlapping
10-48 0.025-0.2 5-30 1.15 1 roll 2 rolls overlapping
10-48 0.025-0.2 5-30 1.2 1 roll 2 rolls overlapping
10-48 0.025-0.2 5-30 1.25 1 roll 2 rolls overlapping
Key Features & Benefits:

  • Enhanced Thermal Insulation: Aluminum foil reflects up to 97% of radiant heat, significantly improving energy efficiency.

  • Excellent Vapor Barrier: FSK facing prevents moisture penetration, protecting structures from mold and condensation.

  • Superior Sound Absorption: Effectively reduces mid to low-frequency noise, ideal for mechanical rooms and studios.

  • Fire-Safe & Non-Toxic: Class A fire rating (non-combustible) and low VOC emissions ensure safe indoor use.

  • Easy Installation: Lightweight, flexible, and can be easily cut to fit complex shapes without specialized tools.

Advanced Aluminum Foil-Faced Glass Wool Blanket – Superior Thermal & Acoustic Barrier 2
Packaging & Lead Time:

  • Standard Export Packing: Vacuum-sealed plastic bag + woven bag

  • OEM Packaging Available

  • Lead Time: 10–15 working days for one 40HC container

Advanced Aluminum Foil-Faced Glass Wool Blanket – Superior Thermal & Acoustic Barrier 3 Advanced Aluminum Foil-Faced Glass Wool Blanket – Superior Thermal & Acoustic Barrier 4
