| resistencia al fuego: | No combustible, Clase A1 | Densidad: | 40-200 kg/m³ |
|---|---|---|---|
| Aplicaciones: | Aislamiento de edificios, equipos industriales, sistemas HVAC. | Absorción de agua: | <1% en volumen |
| Nombre del producto: | Lana mineral de aislamiento térmico | CompresiónFuerza: | ≥20kPa |
| Espesor: | 25-100 milímetros | Color: | Normalmente amarillo o marrón |
| Impacto ambiental: | Reciclable y ecológico | Conductividad térmica: | 0,035 W/m·K |
| Resistencia a la temperatura: | -268°C a 700°C | Dimensiones: | Varía (p. ej., tableros de 600x1200 mm) |
| Material: | Lana mineral | coeficiente de absorción acústica: | 0,85 (promedio) |
| Método de instalación: | Fijación mecánica o unión adhesiva | ||
| Resaltar: | fiberglass ceiling tile design-friendly,fiberglass ceiling tile soundproof,eco-friendly fiberglass ceiling tile |
||
The FANRYN Fiberglass Ceiling Board is more than just a functional building material—it's a design tool. The smooth, decorative fiberglass tissue or optional PVC facing provides a clean, professional canvas. Choose from standard white, bold black, or order custom colors to match your brand or design vision. The square, sealed edges ensure a tight, seamless fit with exposed grid systems, resulting in a crisp, modern look.
Crisp, Clean Lines: The sealed square edges prevent dust accumulation and create a sharp shadow line against the grid.
Color Flexibility: Go beyond basic white. Black ceilings make a dramatic statement, while custom colors allow for total design integration.
Trimmable & Adaptable: Easily cut on-site to fit any floor plan, around corners, columns, or integrate with lighting fixtures.
Sag-Free Guarantee: Unlike some mineral fiber or low-density boards, FANRYN panels maintain their flat, smooth appearance over time, even in humid conditions (tested at 95% RH / 40°C).
Excellent Sound Absorption (NRC 0.9-1.0): In open-plan offices, noise is a top complaint. FANRYN boards absorb up to 100% of sound energy, dramatically reducing distractions and improving focus. In restaurants and retail stores, they lower ambient noise, making conversations easier and stays more pleasant.
Green Building Material: Sustainability is built in. Both the ceiling tiles and their packaging are fully recyclable. By choosing FANRYN, you can contribute to LEED credits and other green building certifications.
Non-Combustible Safety: Made from inorganic fiberglass, the board is naturally non-combustible (Class A), providing a safe environment without relying on chemical fire retardants.
Open Plan Offices: Reduce noise distractions for better productivity.
Restaurants & Cafes: Create a comfortable, intimate atmosphere where patrons can talk easily.
Retail Stores: Lower background noise to improve the shopping experience and allow for clearer audio announcements.
Hotels & Lobbies: Achieve a quiet, upscale aesthetic in high-traffic areas.
Schools & Daycares: Protect young ears from noise fatigue and create a better learning environment.
Standard White Tissue – Clean, bright, classic.
Black Tissue – Bold, dramatic, modern.
Painted Speckled – Adds texture and visual interest.
Custom Colors & PVC Facing – For unique design requirements.
Density: 90-130 kg/m³ (robust, non-brittle).
Thermal Resistance: ≥0.5 (m²·K/W) – adds energy savings.
Moisture Rate: ≤1% – excellent humidity resistance.
Safety: Complies with radionuclide limits (Ira ≤1.0, Ir ≤1.3).
Designed for standard exposed T-grids (15mm or 24mm).
Supports both inch and centimeter grid spacing.
Lightweight and easy to handle; cuts cleanly with a utility knife.
FANRYN boards are packev d securely in cartons to prevent damage during shipping. The table below shows the optimized loading for 40HQ containers to help you plan your project logistics.
| Panel Size (mm) | Cartons / 40HQ | Pieces / Carton | Total Coverage / 40HQ |
|---|---|---|---|
| 600x600x15 | 532 | 20 | 3830.4 m² |
| 600x1200x15 | 266 | 20 | 3830.4 m² |
| 600x600x20 | 532 | 15 | 2872.8 m² |
| 600x1200x20 | 266 | 15 | 2872.8 m² |
| 600x600x25 | 532 | 12 | 2298.24 m² |
| 600x1200x25 | 266 | 12 | 2298.24 m² |
